Honda Prelude V (1996-2001) set/decel sig input resume/accel sig in wiring diagram
This page shows the only wiring diagram for the component.set/decel sig input resume/accel sig in, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
set/decel sig input resume/accel sig in wiring diagram (1 of 1)
1 3 (1997-98) (1999-01)
3 1 (1997-98) (1999-01)
3 5 (1997-98) (1999-01)
5 3 (1997-98) (1999-01)
A/T
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRAKE SWITCH (ON TOP OF BRAKE PEDAL SUPPORT)
BRN WIRE
BRN/BLK WIRE
BRN/WHT WIRE
CABLE REEL (ON TOP OF STEERING COLUMN, BELOW STEERING WHEEL)
CANADA
CLUTCH SWITCH (ON TOP OF CLUTCH PEDAL SUPPORT)
CRUISE CONTROL ACTUATOR (ON RIGHT REAR OF ENGINE COMPARTMENT)
CRUISE CONTROL INDICATOR LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL MAIN SWITCH LIGHT
CRUISE CONTROL SET/ RESUME SWITCH
CRUISE CONTROL UNIT (BEHIND DASH, ABOVE ACCELERATOR PEDAL)
DIMMING CIRCUIT
GAUGE ASSEMBLY
GRN WIRE
GRY WIRE
HORN RELAY (ABOVE UNDERDASH FUSE/RELAY BOX, ON BRACKET)
HORNS SYSTEM
HOT AT ALL TIMES
HOT IN ON OR START
LT GRN WIRE
LT GRN/BLK WIRE
LT GRN/BLU WIRE
LT GRN/RED WIRE
M/T
METER CRUISE CONTROL FUSE 13
OFF ON
ON INDICATOR
PNK A/T GEAR POSITION SWITCH (ON LOWER REAR OF TRANSAXLE) WIRE
PNK WIRE
RED WIRE
RED/WHT WIRE
RESUME/ ACCEL SWITCH
SAFETY SOLENOID VENT SOLENOID
SET/ DECEL SWITCH
SET/DECEL SIG INPUT RESUME/ACCEL SIG IN
STEERING WHEEL)
STOP HORN FUSE 41
U.S.
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
VACUUM SOLENOID
VEHICLE SPEED SENSER (VSS) (ON TOP LEFT OF TRANSAXLE)
VSS OUTPUT PNK WIRE
WHT WIRE
WHT/BLK WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Cruise control circuit -> SET/DECEL SIG INPUT RESUME/ACCEL SIG IN
