Honda Prelude V (1996-2001) rear defogger switch Wiring diagram
This page shows the only wiring diagram for the component.rear defogger switch, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger switch (1 of 1)
BLK WIRE
BLK/GRN WIRE
BRN WIRE
BRN/YEL WIRE
DIMMING CIRCUIT
DRIVER'S MULTIPLEX CONTROL UNIT
GRN WIRE
HEATER CONTROL PANEL
HOT AT ALL TIMES
HOT IN ON
ON IND.
R/C MIRROR FUSE 9
REAR DEFOGGER SWITCH
REAR DEFROSTER FUSE 34
REAR DEFROSTER RELAY FUSE 11
REAR DFGGR RELAY CNTL
REAR FFGGR SW INPUT
REAR WINDOW DEFOGGER
REAR WINDOW DEFOGGER COIL (ON UNDERSIDE OF REAR SHELF)
REAR WINDOW DEFOGGER RELAY
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
YEL/WHT WIRE
