Honda Prelude V (1996-2001) power window master switch light Wiring diagram
This page shows the only wiring diagram for the component.power window master switch light, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power window master switch light (1 of 1)
AUTO DN
BATT INPUT
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BRN WIRE
CONTROL UNIT)
DN PASSENGER'S SWITCH
DOOR D-LINE
DOOR MULTIPLEX CONTROL UNIT (IN DRIVER'S DOOR)
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S SWITCH
DRIVER'S WINDOW MOTOR
GRN WIRE
GRN/WHT WIRE
MAIN SWITCH
P/W ASSISTANT FUSE 16
P/W DRIVER FUSE 15
POWER WINDOW MASTER SWITCH
POWER WINDOW MASTER SWITCH LIGHT
POWER WINDOW RELAY
PWR WDO RLY CTRL
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
UNDERDASH FUSE/RELAY BOX
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power window circuit (2 of 2) -> POWER WINDOW MASTER SWITCH LIGHT
