Honda Prelude V (1996-2001) lock output Wiring diagram
This page shows the only wiring diagram for the component.lock output, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lock output (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
DOOR LOCKS SYSTEM
DRIVER'S DOOR SWITCH (IN LEFT "B" PILLAR)
GRN WIRE
GRN/ORG WIRE
HOT IN ON OR
KEYLESS RECEIVER UNIT (ON LEFT QUARTER PANEL, FORWARD OF WHEELWELL)
LOCK OUTPUT
ORG/ WIRE
PASSENGER'S DOOR SWITCH (IN RIGHT "B" PILLAR)
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/WHT WIRE
SECURITY DIODES (BEHIND DRIVER'S LEFT AIR VENT)
SECURITY IN-LINE FUSE HOLDER 1 (BEHIND DASH, ABOVE LEFT KICK PANEL)
SIREN (BEHIND LEFT SIDE OF FRONT BUMPER) (OPTIONAL)
TRUNK LATCH SWITCH (ON CENTER OF TRUNK LID, AT LATCH ASSEMBLY)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL) ECU EAT ECU FUSE 14
UNLOCK OUTPUT
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (2 of 2) -> LOCK OUTPUT
