Honda Prelude V (1996-2001) left tail light Wiring diagrams
This page contains all the electrical diagrams for the component. left tail light, in which he is found in the car Honda Prelude V (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left tail light (1 of 2)
BACKUP LAMPS CIRCUIT
BLK WIRE
BLK/ WHT WIRE
BRAKE SWITCH (BEHIND DASH, ON TOP OF BRAKE PEDAL SUPPORT)
BULB TYPE
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
GRN/ WHT WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEAD OFF PARK
HEADLIGHT SWITCH (PART OF COMBINATION LIGHT SWITCH)
HIGH MOUNT BRAKE LIGHT
HIGH MOUNT BRAKE LIGHT (TYPE SH)
HOT AT ALL TIMES
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL LIGHT
LICENSE PLATE LIGHT
RED/ BLK WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
SECURITY SYSTEM CONNECTOR (CANADA)
SMALL LIGHT FUSE 42
STOP HORN FUSE 41
TAIL LIGHT FUSE 10
TO UNDERDASH FUSE/RELAY BOX (DIAGRAM 2 OF 2)
TRAILER LIGHTING CONNECTOR (ON LEFT REAR OF TRUNK, TAPED TO HARNESS)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
UNDERHOOD FUSE/RELAY BOX (ON RIGHT REAR CORNER OF ENGINE COMPARTMENT)
W/ SPOILER
WHT GRN/ WIRE
WHT YEL/ WIRE
WHT/ BLK WIRE
WHT/BLK WIRE
YEL/ WHT WIRE
Go to component -> Exterior lamps circuit (1 of 2) -> LEFT TAIL LIGHT
Wiring diagram left tail light (2 of 2)
BLK WIRE
HEATER CONTROL PANEL
HEATER FAN SWITCH
HIGH MOUNT BRAKE LIGHT (TYPE SH)
LEFT BACK-UP LIGHT
LEFT BRAKE LIGHT/ TAILLIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT REAR TURN SIGNAL LIGHT
LEFT TAIL LIGHT
LICENSE PLATE LIGHT
RED/BLK WIRE
RIGHT BACK-UP LIGHT
RIGHT BRAKE LIGHT/ TAILLIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN SIGNAL LIGHT
RIGHT TAIL LIGHT
TRAILER LIGHTING CONNECTOR
TRUNK LATCH SWITCH
Go to component -> Ground distribution circuit (4 of 4) -> LEFT TAIL LIGHT
