Honda Prelude V (1996-2001) ind ctrl ignition mes in service chk airbag ctrl Wiring diagram
This page shows the only wiring diagram for the component.ind ctrl ignition mes in service chk airbag ctrl, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ind ctrl ignition mes in service chk airbag ctrl (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 AIRBAG CTRL
AIRBAG CTRL AIRBAG CTRL DLC GROUND GROUND MES IN
BLK WIRE
BLU WIRE
CABLE REEL
DATA LINK CONNECTOR (DLC) (PARTIAL) (ON LEFT SIDE OF FRONT PASSENGER'S FOOTWELL)
DRIVER'S AIR BAG
FRONT PASSENGER'S AIR BAG
FUSE 13
FUSE 23
GAUGE ASSEMBLY
GRY WIRE
HOT IN ON OR START
IGNITION
IND CTRL IGNITION MES IN SERVICE CHK AIRBAG CTRL
LT GRN WIRE
LT GRN/RED WIRE
RED WIRE
RED/WHT WIRE
SERVICE CHECK CONNECTOR (PARTIAL) (ON LEFT SIDE OF FRONT PASSENGER'S FOOTWELL)
SRS FUSE BLOCK (ON FRONT OF UNDERDASH FUSE/RELAY BOX) FUSE 24
SRS INDICATOR
SRS INDICATOR CIRCUIT
SRS MEMORY ERASE SIGNAL (MES) CONNECTOR (BEHIND DASH, LEFT OF STEERING COLUMN)
SRS UNIT (BELOW CENTER OF DASH)
STEERING WHEEL)
UNDERDASH FUSE/RELAY BOX (BEHIND LEFT KICK PANEL)
WHT WIRE
YEL WIRE
Go to component -> Supplemental restraint circuit -> IND CTRL IGNITION MES IN SERVICE CHK AIRBAG CTRL
