Honda Prelude V (1996-2001) ground sec ind ctrl ign key sw input Wiring diagram
This page shows the only wiring diagram for the component.ground sec ind ctrl ign key sw input, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ground sec ind ctrl ign key sw input (1 of 1)
ANTENNA
ANTENNA INPUT
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CLOCK RADIO FUSE 43
DISARM/ VALET SWITCH (ON LOWER LEFT DASH PANEL)
EXTERIOR, INTERIOR LIGHT SYSTEMS
GLASS BREAKAGE MICROPHONE
GRN WIRE
GRN/ORG WIRE
GROUND SEC IND CTRL IGN KEY SW INPUT
HOOD SWITCH (ON FRONT OF ENGINE COMPARTMENT, NEXT TO HOOD LATCH)
HORNS SYSTEM
HOT AT ALL TIMES
IGNITION KEY SWITCH
LIGHT FLASH CTRL HORN CTRL
LIGHT FLASHER RELAY (ON BACK OF LOWER LEFT DASH PANEL)
LT GRN/BLU WIRE
NCA WIRE
OPTIONAL
ORG/ WIRE
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
SECURITY CONTROL UNIT (BEHIND DASH, ABOVE ACCELERATOR PEDAL)
SECURITY IN-LINE FUSE HOLDER 2 (BEHIND DASH, ABOVE LEFT KICK PANEL)
SECURITY INDICATOR
SIREN CTRL LOCK INPUT
STEERING LOCK
WARNING SYSTEMS
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit (1 of 2) -> GROUND SEC IND CTRL IGN KEY SW INPUT
