Honda Prelude V (1996-2001) dlc in/out countershaft spd sensor ground mainshaft speed Wiring diagram

A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A (ON RIGHT REAR SIDE OF TRANSAXLE) A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE B (ON RIGHT REAR SIDE OF TRANSAXLE) A/T GEAR POSITION INDICATOR A/T GEAR POSITION SWITCH ATPNP BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE SWITCH (TOP OF BRAKE PEDAL SUPPORT) BRN WIRE BRN/BLK WIRE CLUT PRES CTRL A+ CLUT PRES CTRL A- CLUT PRES CTRL B- CLUT PRES CTRL B+ BRAKE SW INPUT MODE SW IN CLUTCH PRESSURE SWITCH (TOP REAR OF TRANS- MISSION) COUNTERSHAFT SPEED SENSOR (TOP OF DIMMING CIRCUIT DLC IN/OUT COUNTERSHAFT SPD SENSOR GROUND MAINSHAFT SPEED DRIVE INPUTS ECT ENGINE CONTROL MODULE (ON UNDERSIDE OF PASSENGER'S FOOTREST) ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENG, BELOW DISTRIBUTOR) FUSE 41 GAUGE ASSEMBLY GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/WHT WIRE GRN/YEL WIRE HOT AT ALL TIMES HOT IN ON OR START IGNITION CONTROL MODULE IGNITION INPUT GROUND J/C LOCK-UP CONTROL SOLENOID LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE MAINSHAFT SPEED SENSOR MODE SW NCA WIRE ORG/ WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE SEAF SEFA SHIFT CONTROL SOLENOID VALVE SHIFT CONTROL SOLENOID VALVES B, C (LOWER FRONT OF TRANSMISSION) SHIFT IND CIRCUIT SHIFT IND CTRL C SHIFT IND CTRL B SHIFT IND CTRL A SHIFT LOCK CTRL BATTERY INPUT SHIFT INTER- LOCK SYSTEM SHIFT SOL CTRL B SHIFT SOL CTRL A NEUTRAL IN ENGINE SPD INPUT SHIFT SW IN - SHIFT SW IN + SENSOR GROUND SHIFT SW MODE SWITCH TEST TACHOMETER CONNECTOR (ON FRONT OF RIGHT STRUT TOWER) THROTTLE POSITION SENSOR TP SENSOR INPUT VSS INPUT TRANS CTRL DATA PGM-FI CTRL DATA TRANSAXLE TRANSMISSION CONTROL MODULE (ON UNDERSIDE OF FRONT PASSENGER'S FOOTREST) UNDERDASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDERDASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 14 UNDERHOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENG COMP) FUSE 43 VEHICLE SPEED SENSOR (RIGHT SIDE OF ENG) (TOP OF TRANSAXLE) VREF WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLU WIRE
