Honda Prelude V (1996-2001) daytime running lights control unit seat heater relay Wiring diagram
This page shows the only wiring diagram for the component.daytime running lights control unit seat heater relay, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram daytime running lights control unit seat heater relay (1 of 1)
14 20 (1997-98) (1999-01)
5 3 (1997-98) (1999-01)
A/T
A/T GEAR POSITION SWITCH
ABS CONTROL UNIT
ABS FAIL-SAFE RELAY
ASHTRAY LIGHT
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BRAIDED WIRE
CANADA
COIL
CRUISE CONTROL ACTUATOR
DATA LINK CONNECTOR
DAYTIME RUNNING LIGHTS CONTROL UNIT SEAT HEATER RELAY
DIMMER RELAY
DOOR LOCK RELAY
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR LOCK ASSEMBLY
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT HEATER
EVAPORATIVE EMISSION PURGE FLOW SWITCH (1997 EXCEPT CALIFORNIA)
FUEL PUMP
FUEL TANK UNIT
GRY WIRE
HIGH MOUNT BRAKE LIGHT (BULB TYPE)
KEYLESS RECEIVER UNIT
LEFT POWER MIRROR
MODE SWITCH
MULTIPLEX CONTROL UNIT INSPECTION CONNECTOR
PARKING PIN SWITCH
PASSENGER'S DOOR KEY CYLINDER SWITCH
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S SEAT HEATER
PASSENGER'S SEAT HEATER SWITCH
PASSENGERS DOOR LOCK SWITCH
RED WIRE
RED/WHT WIRE
RIGHT POWER MIRROR
SHIFT LOCK RELAY
SRS UNIT
STEREO AMPLIFIER
STEREO AMPLIFIER SHIELD
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Ground distribution circuit (3 of 4) -> DAYTIME RUNNING LIGHTS CONTROL UNIT SEAT HEATER RELAY
