Honda Prelude V (1996-2001) a/c compressor clutch relay condenser fan relay Wiring diagram
This page shows the only wiring diagram for the component.a/c compressor clutch relay condenser fan relay, which is found in the car Honda Prelude V (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c compressor clutch relay condenser fan relay (1 of 1)
1997 EARLY PRODUCTION
3 5 (1997-98) (1999-01)
A/C COMPRESSOR CLUTCH RELAY CONDENSER FAN RELAY
A/C THERMOSTAT
ABS CONTROL UNIT
ATTS CONTROL UNIT (TYPE SH)
BLK/WHT WIRE
BLK/YEL WIRE
BLOWER MOTOR RELAY
BLU/RED WIRE
CANADA
COIL
COIL COIL
DAY LIGHT UNIT FUSE 12
DAYTIME RUNNING LIGHTS CONTROL UNIT (CANADA)
ENGINE CONTROL MODULE
EXCEPT 1997 EARLY PRODUCTION
FROM FUSE 35 (DIAGRAM 1 OF 5)
IG SW FUSE 33
IGNITION SWITCH
J/C
LOCK
NCA WIRE
PGM-FI MAIN RELAY
POWER MIRROR SWITCH SEAT HEATER RELAY (CANADA)
R/C MIRROR FUSE 9
RADIATOR FAN RELAY
REAR DEFROSTER RELAY FUSE 11
REAR WINDOW DEFOGGER RELAY
RECIRCULATION CONTROL MOTOR HEATER CONTROL PANEL
SRS FUSE BLOCK
STARTER CUT RELAY
STARTER SIGNAL FUSE 2
STARTING/ CHARGING SYSTEM
TO FUSE 42
TO SRS FUSE BLOCK (DIAGRAM 3 OF 5)
TO SRS FUSE BLOCK (DIAGRAM 4 OF 5)
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (2 of 5) -> A/C COMPRESSOR CLUTCH RELAY CONDENSER FAN RELAY
