Honda Prelude V (1996-2001) abs fail-safe relay Wiring diagrams
This page contains all the electrical diagrams for the component. abs fail-safe relay, in which he is found in the car Honda Prelude V (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram abs fail-safe relay (1 of 2)
14 20 (1997-98) (1999-01)
5 3 (1997-98) (1999-01)
A/T
A/T GEAR POSITION SWITCH
ABS CONTROL UNIT
ABS FAIL-SAFE RELAY
ASHTRAY LIGHT
AUDIO UNIT
BLK WIRE
BLK/WHT WIRE
BRAIDED WIRE
CANADA
COIL
CRUISE CONTROL ACTUATOR
DATA LINK CONNECTOR
DAYTIME RUNNING LIGHTS CONTROL UNIT SEAT HEATER RELAY
DIMMER RELAY
DOOR LOCK RELAY
DOOR MULTIPLEX CONTROL UNIT
DRIVER'S DOOR LOCK ASSEMBLY
DRIVER'S MULTIPLEX CONTROL UNIT
DRIVER'S SEAT BELT SWITCH
DRIVER'S SEAT HEATER
EVAPORATIVE EMISSION PURGE FLOW SWITCH (1997 EXCEPT CALIFORNIA)
FUEL PUMP
FUEL TANK UNIT
GRY WIRE
HIGH MOUNT BRAKE LIGHT (BULB TYPE)
KEYLESS RECEIVER UNIT
LEFT POWER MIRROR
MODE SWITCH
MULTIPLEX CONTROL UNIT INSPECTION CONNECTOR
PARKING PIN SWITCH
PASSENGER'S DOOR KEY CYLINDER SWITCH
PASSENGER'S MULTIPLEX CONTROL UNIT
PASSENGER'S SEAT HEATER
PASSENGER'S SEAT HEATER SWITCH
PASSENGERS DOOR LOCK SWITCH
RED WIRE
RED/WHT WIRE
RIGHT POWER MIRROR
SHIFT LOCK RELAY
SRS UNIT
STEREO AMPLIFIER
STEREO AMPLIFIER SHIELD
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
Go to component -> Ground distribution circuit (3 of 4) -> ABS FAIL-SAFE RELAY
Wiring diagram abs fail-safe relay (2 of 2)
3 5 (1997-98) (1999-01) COIL CONTACT
ABS +B FUSE 40
ABS FAIL-SAFE RELAY
ABS MOTOR FUSE 31
ABS PUMP MOTOR RELAY
ACG-S FUSE 4
ALTERNATOR
ATTS FAIL- SAFE RELAY (TYPE SH)
ATTS UNIT FUSE 1
BATTERY
BATTERY FUSE 32
BLK WIRE
BLOWER MOTOR RELAY
BRAKE SWITCH
DAY LIGHT FUSE 8
DAYTIME RUNNING LIGHTS CONTROL UNIT (CANADA)
ELECTRICAL LOAD DETECTOR (ELD) UNIT
FROM FUSE 31 (DIAGRAM 1 OF 5)
FUSE BOX FUSE 36
HAZARD FUSE 39
HAZARD WARNING SWITCH
HEATED SEAT FUSE 6
HEATER MOTOR FUSE 35
HORN RELAY
IMMOBILIZER CONTROL UNIT
MOON ROOF CLOSE RELAY
MOON ROOF OPEN RELAY
PGM-FI MAIN RELAY
POWER WINDOW FUSE 37
POWER WINDOW RELAY REAR WINDOW DEFOGGER RELAY
REAR DEFROSTER FUSE 34
RED/BLU WIRE
RR SPEAKER FUSE 5
SEAT HEATER RELAY (CANADA)
STARTER
STARTER SOLENOID
STEERING LOCK
STEREO AMPLIFIER
STOP HORN FUSE 41
SUN ROOF FUSE 7
TO FUSE 33 (DIAGRAM 2 OF 5)
TO FUSE 38 (DIAGRAM 1 OF 5)
TURN SIGNAL/ HAZARD RELAY
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> ABS FAIL-SAFE RELAY
