Sub gauge assembly circuit, with electro-luminescent gauges (1 of 2) for Honda Prelude IV (1992-1996)

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/YEL WIRE BRN WIRE DC/AC INVERTER (LEFT SIDE OF MAIN GAUGE ASSEMBLY) ENGINE CONTROLS SYSTEM TRANSMISSIONS SYSTEM FROM SUB-GAUGE ASSEMBLY FUSE 13 FUSE 43 CLOCK/RADIO GRN WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HIGH BEAM HOT AT ALL TIMES HOT IN ON OR START LEFT TURN LT GRN WIRE LT GRN/WHT WIRE MAIN GAUGE ASSEMBLY NCA WIRE ORG/ WIRE ORG/BLU WIRE ORG/WHT WIRE PNK ELECTRONIC POWER STEERING WIRE PNK WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT TURN SRS INDIC SRS INDICATOR DRIVER, DIMMER CONTROL CIRCUITS SUPPLEMENTAL RESTRAINTS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM TO MAIN GAUGE ASSEMBLY TRANSMISSIONS SYSTEM UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPARTMENT) WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE
