Honda Prelude IV (1992-1996) yel Wiring diagrams
This page contains all the electrical diagrams for the component. yel, in which he is found in the car Honda Prelude IV (1992-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram yel (21 of 31)
Go to component -> Charging circuit -> YEL WIRE
Wiring diagram yel (22 of 31)
Go to component -> Power distribution circuit (4 of 5) -> YEL WIRE
Wiring diagram yel (23 of 31)
Go to component -> Power mirror circuit -> YEL WIRE
Wiring diagram yel (24 of 31)
Go to component -> Power window circuit -> YEL WIRE
Wiring diagram yel (25 of 31)
Go to component -> Radio circuits, base radio -> YEL WIRE
Wiring diagram yel (26 of 31)
Go to component -> Radio circuits, premium radio -> YEL WIRE
Wiring diagram yel (27 of 31)
Go to component -> Shift interlock circuit -> YEL WIRE
Wiring diagram yel (28 of 31)
Go to component -> Sunroof circuit -> YEL WIRE
Wiring diagram yel (29 of 31)
Go to component -> Supplemental restraint circuit -> YEL WIRE
Wiring diagram yel (30 of 31)
Go to component -> Transmission circuit -> YEL WIRE
