Honda Prelude IV (1992-1996) wind- shield wiper/ washer switch Wiring diagram

This page shows the only wiring diagram for the component.wind- shield wiper/ washer switch, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram wind- shield wiper/ washer switch (1 of 1)

Wiring diagram wind- shield wiper/ washer switch for Honda Prelude IV (1992-1996)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE FUSE 17 GRN WIRE GRN/BLK WIRE GRN/RED WIRE GROUND HOT IN ON OR START INT LO INT WIPE INPUT INTEGRATED CONTROL UNIT INTERMITTENT WIPER CIRCUIT LEFT FRONT FENDER) MIST OFF PARK PARK INPUT RUN WIRE UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) WASH WASHER ON INPUT WIND- SHIELD WIPER/ WASHER SWITCH WINDSHIELD WASHER MOTOR (BEHIND LOWER LEFT FRONT BUMPER FASCIA) WINDSHIELD WIPER INTERMITTENT RELAY (LEFT REAR CORNER OF ENGINE COMPARTMENT) WINDSHIELD WIPER MOTOR (BEHIND LEFT SIDE OF AIR SCOOP) WIPE INT CTRL

Go to component: -> Wiper/washer circuit -> WIND- SHIELD WIPER/ WASHER SWITCH
