Honda Prelude IV (1992-1996) to under-dash fuse/relay box pin 10 Wiring diagram
This page shows the only wiring diagram for the component.to under-dash fuse/relay box pin 10, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to under-dash fuse/relay box pin 10 (1 of 1)
A/T GEAR POSITION SWITCH
ABS FRONT FAIL-SAFE RELAY
ABS PRESSURE SWITCH
ABS REAR FAIL-SAFE RELAY
BLK BLK BLK WIRE
BLK BLK WIRE
BLK WIRE
BLK/WHT WIRE
CEILING LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL UNIT
DASH LIGHTS BRIGHTNESS CONTROL UNIT
DAYTIME RUNNING LIGHTS CONTROL UNIT (CANADA)
DRIVER'S POWER MIRROR (CANADA)
DRIVER'S POWER WINDOW MOTOR
FUEL TANK UNIT
HEATER CONTROL PANEL
HIGH MOUNT BRAKE LIGHT
INTERLOCK CONTROL UNIT
LEFT LICENSE LIGHT
MAIN GAUGE ASSEMBLY
MAIN GAUGE ASSEMBLY (WITH LUMINESCENT GAUGES)
MAIN GAUGE ASSEMBLY (WITHOUT LUMINESCENT GAUGES)
MASTER POWER WINDOW SWITCH
PASSENGER'S DOOR LOCK LATCH ASSEMBLY
PASSENGER'S POWER MIRROR (CANADA)
PASSENGERS DOOR LOCK SWITCH
RADIATOR FAN CONTROL MODULE
RIGHT LICENSE LIGHT
SUB GAUGE ASSEMBLY
SUNROOF SWITCH
THERMISTOR
TO UNDER-DASH FUSE/RELAY BOX PIN 10
TRUNK LATCH SWITCH
WOOFER AMPLIFIER (VTEC,SR-V) DRIVER'S SEAT BELT SWITCH
YEL WIRE
Go to component: -> Ground distribution circuit (2 of 4) -> TO UNDER-DASH FUSE/RELAY BOX PIN 10
