Honda Prelude IV (1992-1996) to cigarette lighter relay Wiring diagram
This page shows the only wiring diagram for the component.to cigarette lighter relay, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram to cigarette lighter relay (1 of 1)
A/T
A/T GEAR POSITION SWITCH
AUXILLARY FUSE HOLDER FUSE 22
BACK-UP LIGHT SWITCH
BLK/RED WIRE
BLK/YEL WIRE
CONTROL UNIT)
CRUISE CONTROL MAIN SWITCH
FROM FUSE 14
FROM IGNITION SWITCH
FRONT MAIN STEERING ANGLE SENSOR
FUSE 13
FUSE 14
FUSE 17
FUSE 18
GRN/BLK WIRE
GRN/RED WIRE
IGNITION COIL
IN-LINE DIODE (W/ LUMINESCENT GAUGES)
INTEGRATED CONTROL UNIT
JUNCTION CONNECTOR 3 (BEHIND RIGHT QUARTER TRIM PANEL)
JUNCTION CONNECTOR 4 (RIGHT SIDE OF DASH)
JUNCTION CONNECTOR 5 (ABOVE LEFT KICK PANEL)
M/T
MAIN GAUGE ASSEMBLY
REAR MAIN STEERING ANGLE SENSOR
RED WIRE
SECURITY SYSTEM CONNECTOR
SHIFT LOCK SOLENOID
SRS FUSE BLOCK
STEREO RADIO/ CASSETTE PLAYER
SUB GAUGE ASSEMBLY
TO CIGARETTE LIGHTER RELAY
TO FUSE #17
TO FUSE 23
TURN SIGNAL DIODE
UNDERDASH FUSE/RELAY BOX
WHT/BLK WIRE
WINDSHIELD INTERMITTENT WIPER RELAY
WINDSHIELD WIPER MOTOR
WINDSHIELD WIPER/WASHER SWITCH
WOOFER AMPLIFIER (VTEC,SR-V)
YEL WIRE
YEL/RED WIRE
Go to component: -> Power distribution circuit (4 of 5) -> TO CIGARETTE LIGHTER RELAY
