Honda Prelude IV (1992-1996) srs memory erase signal connector Wiring diagram

This page shows the only wiring diagram for the component.srs memory erase signal connector, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram srs memory erase signal connector (1 of 1)

Wiring diagram srs memory erase signal connector for Honda Prelude IV (1992-1996)

Get access

BLK WIRE BLU WIRE BRN WIRE CABLE REEL (TOP OF STEERING COLUMN) COWL SENSOR DASH SENSOR DATA LINK CONNECTOR (BEHIND FRONT CONSOLE) DRIVER'S AIRBAG INFLATOR FRONT PASSENGER'S AIRBAG INFLATOR (RIGHT SIDE OF I/P) FUSE 24 GAUGE ASSEMBLY GRY WIRE HOT IN ON OR START SRS FUSE BLOCK (LEFT KICK PANEL) FUSE 23 HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 13 INDICATOR CIRCUIT LT GRN WIRE MONITOR CIRCUIT NCA WIRE RED WIRE SERVICE CHECK CONNECTOR (BEHIND FRONT CONSOLE) SRS INDICATOR SRS MEMORY ERASE SIGNAL CONNECTOR SRS UNIT (BELOW CENTER OF I/P) STEERING WHEEL) WHT WIRE YEL WIRE

Go to component: -> Supplemental restraint circuit -> SRS MEMORY ERASE SIGNAL CONNECTOR
