Honda Prelude IV (1992-1996) shift interlock system Wiring diagrams

A/T BATTERY INPUT BLK WIRE DOOR SWITCH INPUT DRIVER'S DOOR SWITCH ENTRY LIGHT TIMER (INTEGRATED CONTROL UNIT) FUSE 46 INTERIOR LIGHTS GRN/BLU WIRE GROUND HOT AT ALL TIMES IGN KEY LIGHT CTRL IGNITION KEY LIGHT STEERING LOCK ASSEMBLY M/T SHIFT INTERLOCK SYSTEM UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPARTMENT) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/YEL WIRE

1994 MODELS W/O LUMINESCENT GAUGES, 1993 MODELS A/C ON INPUT IGNITION INPUT IGNITION INPUT GROUND GROUND A/T GEAR POSITION CONSOLE LIGHT 1 2 A/T GEAR POSITION INDICATOR A/T GEAR POSITION SWITCH (LEFT OF GEAR SELECTOR) AFSA AFSB AIR CONDITIONING SYSTEM ANTI-THEFT SYSTEM ATP PN BLK WIRE BLK/ YEL WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU ORG WIRE BLU WIRE BLU/ GRN WIRE BLU/ WHT WIRE BLU/ YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRAKE SW INPUT BRAKE SWITCH (LEFT SIDE OF I/P) BRN BLK/ WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE COUNTERSHAFT SPEED SENSOR (REAR OF TRANSMISSION) CRUISE CONTROL SYSTEM DIMMING CIRCUIT DISTRIBUTOR ASSEMBLY DRIVE INPUT REVERSE INPUT DRIVE INPUTS ECT ECT SENSOR INPUT SERVICE CHK CONN TP SENSOR INPUT ENGINE CONTROL MODULE (RIGHT FRONT OF FLOOR) ENGINE COOLANT TEMPERATURE SENSOR (RIGHT SIDE OF ENGINE) FAS FUSE 13 FUSE 23 FUSE 43 CLOCK/RAD GAUGE ASSEMBLY GRN WIRE GRN/ WHT WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/ORG WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRNWHT HOT IN ON OR START IGNITION CONTROL MODULE LOCK-UP CONTROL SOLENOID VALVES THROTTLE POSITION SENSOR LT GRN WIRE LT GRN/BLK WIRE LT GRN/WHT WIRE MAINSHAFT SPEED MAINSHAFT SPEED SENSOR (FRONT OF TRANSMISSION) NCA WIRE ORG/ WIRE ORG/BLU WIRE ORG/RED WIRE PNK PNK WIRE PNK UP/DN SHIFT SIG SENSOR GROUND UP/DN SHIFT SIG WIRE PNK WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR ENG COMPT, SCS SENSOR GROUND SHIFT ACKNOWLEDGE COUNTERSHAFT SPD SERVICE CHECK CONNECTOR (BEHIND FRONT CONSOLE) SHIFT CONTROL SOLENOID VALVES SHIFT INTERLOCK SYSTEM SHIFT LOCK CTRL PARK/NEUTR INPUT BATTERY INPUT SRS FUSE BLOCK (LEFT KICK PANEL) TEST TACHOMETER CONNECTOR (RIGHT SIDE OF ENGINE COMPARTMENT) TPS UNDER-DASH FUSE-RELAY BOX (LEFT KICK PANEL) UNDER-DASH FUSE/RELAY BOX UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) VEHICLE SPEED SENSOR VREF VSS INPUT W LUMINESCENT GAUGES WHT BRN WIRE WHT GRN/ WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/ WHT WIRE YEL/BLU WIRE YEL/WHT WIRE
