Honda Prelude IV (1992-1996) security indicator Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 (IF EQUIPPED) (IF EQUIPPED) 1995 VFTC BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE DISARM/ VALET SWITCH DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM WARNING SYSTEM FUSE 42 SMALL LIGHT FUSE 43 CLOCK/RADIO GLASS BREAKAGE MICROPHONE GRN WIRE GRN/BLK WIRE HOOD SWITCH (OPTIONAL) (BEHIND CENTER OF FRONT BUMPER) HOT AT ALL TIMES HOT IN ON OR START IGNITION KEY SWITCH INTERIOR LIGHTS SYTEM LIGHT FLASHER RELAY (RIGHT SIDE OF STEERING COLUMN) NCA WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE SECURITY CONTROL UNIT (UNDERSIDE OF LEFT FRONT SEAT) SECURITY IN- LINE FUSE HOLDER (LEFT KICK PANEL) SECURITY INDICATOR SIREN (OPTIONAL) (BEHIND CENTER OF FRONT BUMPER) STARTING/CHARGING SYSTEM HORNS SYSTEM TRUNK LATCH SWITCH (CENTER OF TRUNK LID) UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 17 UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPARTMENT) WHT WIRE WHT/YEL WIRE YEL/RED WIRE
