Honda Prelude IV (1992-1996) right seat heater switch Wiring diagram

This page shows the only wiring diagram for the component.right seat heater switch, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram right seat heater switch (1 of 1)

Wiring diagram right seat heater switch for Honda Prelude IV (1992-1996)

Get access

BACK BLK WIRE BLK/GRN WIRE BLU WIRE CUSHION) FUSE 6 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT IN ON UNDER-DASH FUSE/RELAY BOX FUSE 11 (LEFT KICK PANEL) LEFT SEAT HEATER LEFT SEAT HEATER RELAY LEFT SEAT HEATER SWITCH NCA WIRE RIGHT SEAT HEATER RIGHT SEAT HEATER RELAY RIGHT SEAT HEATER SWITCH SEAT HEATER MAIN RELAY (BEHIND LEFT I/P) WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE YEL/BLK WIRE

Go to component: -> Heated seats circuit, canada -> RIGHT SEAT HEATER SWITCH
