Honda Prelude IV (1992-1996) passengers door lock switch Wiring diagrams
This page contains all the electrical diagrams for the component. passengers door lock switch, in which he is found in the car Honda Prelude IV (1992-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram passengers door lock switch (1 of 2)
A/T GEAR POSITION SWITCH
ABS FRONT FAIL-SAFE RELAY
ABS PRESSURE SWITCH
ABS REAR FAIL-SAFE RELAY
BLK BLK BLK WIRE
BLK BLK WIRE
BLK WIRE
BLK/WHT WIRE
CEILING LIGHT
CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL UNIT
DASH LIGHTS BRIGHTNESS CONTROL UNIT
DAYTIME RUNNING LIGHTS CONTROL UNIT (CANADA)
DRIVER'S POWER MIRROR (CANADA)
DRIVER'S POWER WINDOW MOTOR
FUEL TANK UNIT
HEATER CONTROL PANEL
HIGH MOUNT BRAKE LIGHT
INTERLOCK CONTROL UNIT
LEFT LICENSE LIGHT
MAIN GAUGE ASSEMBLY
MAIN GAUGE ASSEMBLY (WITH LUMINESCENT GAUGES)
MAIN GAUGE ASSEMBLY (WITHOUT LUMINESCENT GAUGES)
MASTER POWER WINDOW SWITCH
PASSENGER'S DOOR LOCK LATCH ASSEMBLY
PASSENGER'S POWER MIRROR (CANADA)
PASSENGERS DOOR LOCK SWITCH
RADIATOR FAN CONTROL MODULE
RIGHT LICENSE LIGHT
SUB GAUGE ASSEMBLY
SUNROOF SWITCH
THERMISTOR
TO UNDER-DASH FUSE/RELAY BOX PIN 10
TRUNK LATCH SWITCH
WOOFER AMPLIFIER (VTEC,SR-V) DRIVER'S SEAT BELT SWITCH
YEL WIRE
Go to component -> Ground distribution circuit (2 of 4) -> PASSENGERS DOOR LOCK SWITCH
Wiring diagram passengers door lock switch (2 of 2)
1995 VFTC
ANTI-THEFT SYSTEM (OPTIONAL)
BATTERY INPUT
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
DRIVER'S DOOR LOCK LATCH ASSEMBLY
DRIVER'S DOOR LOCK SWITCH
DRIVER'S DOOR SWITCH
FUSE 44 DOOR LOCK
GRN/BLU WIRE
GRN/RED WIRE
GRN/WHT WIRE
GROUND UNLOCK INPUT LOCK INPUT
HOT AT ALL TIMES
IGNITION KEY SWITCH
IGNITION KEY SWITCH INPUT DRIVER'S DOOR SWITCH INPUT PASSENGER'S DOOR SWITCH IN
LOCK
LOCK UNLOCK
PASSENGER'S DOOR LOCK LATCH ASSEMBLY
PASSENGER'S DOOR SWITCH
PASSENGERS DOOR LOCK SWITCH
POWER DOOR LOCK CONTROL UNIT (INSIDE DRIVER'S DOOR)
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPARTMENT)
UNLOCK
UNLOCK LOCK
WHT WIRE
WHT/RED WIRE
YEL/RED WIRE
Go to component -> Power door lock circuit -> PASSENGERS DOOR LOCK SWITCH
