Honda Prelude IV (1992-1996) off on head Wiring diagram
This page shows the only wiring diagram for the component.off on head, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off on head (1 of 1)
BLK WIRE
BLU WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER RELAY
DIMMER SWITCH
FLASH TO PASS SWITCH
FOG LIGHT RELAY (LEFT SIDE OF I/P)
FOG LIGHT SWITCH
FUSE 32
FUSE 51
GRN WIRE
HEADLAMPS CIRCUIT
HEADLIGHT RELAY
HEADLIGHT SWITCH
HEADLIGHTS (CANADA)
HI ON
HOT AT ALL TIMES
HOT AT ALL TIMES UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 3
LEFT FOG LIGHT
OFF ON HEAD
ORG/ WIRE
PARK
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
UNDER-DASH FUSE-RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE-RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
Go to component -> Foglamps -> OFF ON HEAD
