Honda Prelude IV (1992-1996) off on door Wiring diagram

This page shows the only wiring diagram for the component.off on door, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram off on door (1 of 1)

Wiring diagram off on door for Honda Prelude IV (1992-1996)

Get access

ANTI-THEFT SYSTEM (OPTIONAL) BLK WIRE BLK/WHT WIRE BLU/ WHT WIRE CEILING LIGHT CEILING LIGHTS DOOR LOCKS SYSTEM DRIVER'S DOOR SWITCH FUSE 46 INTERIOR LIGHTS GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE HOT AT ALL TIMES INSTRUMENT CLUSTERS SYSTEM OFF ON OFF ON DOOR ON OFF ON OFF DOOR PASS- ENGER'S DOOR SWITCH PASS- ENGER'S DOOR SWITCH DRIVER'S DOOR SWITCH SPOT- LIGHTS SUB GAUGE ASSEMBLY TRUNK LATCH SWITCH TRUNK LIGHT UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX W/ ROOF SPOTLIGHTS W/O ROOF SPOTLIGHTS WHT/ BLK WIRE WHT/ BLU WIRE WHT/BLU WIRE

Go to component: -> Courtesy lamp circuit -> OFF ON DOOR
