Honda Prelude IV (1992-1996) lock unlock Wiring diagram

This page shows the only wiring diagram for the component.lock unlock, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram lock unlock (1 of 1)

Wiring diagram lock unlock for Honda Prelude IV (1992-1996)

Get access

1995 VFTC ANTI-THEFT SYSTEM (OPTIONAL) BATTERY INPUT BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE DRIVER'S DOOR LOCK LATCH ASSEMBLY DRIVER'S DOOR LOCK SWITCH DRIVER'S DOOR SWITCH FUSE 44 DOOR LOCK GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GROUND UNLOCK INPUT LOCK INPUT HOT AT ALL TIMES IGNITION KEY SWITCH IGNITION KEY SWITCH INPUT DRIVER'S DOOR SWITCH INPUT PASSENGER'S DOOR SWITCH IN LOCK LOCK UNLOCK PASSENGER'S DOOR LOCK LATCH ASSEMBLY PASSENGER'S DOOR SWITCH PASSENGERS DOOR LOCK SWITCH POWER DOOR LOCK CONTROL UNIT (INSIDE DRIVER'S DOOR) UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR OF ENGINE COMPARTMENT) UNLOCK UNLOCK LOCK WHT WIRE WHT/RED WIRE YEL/RED WIRE

Go to component: -> Power door lock circuit -> LOCK UNLOCK
