Honda Prelude IV (1992-1996) left front turn signal light Wiring diagram
This page shows the only wiring diagram for the component.left front turn signal light, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front turn signal light (1 of 1)
"S" MODEL ONLY
BATTERY
BLK BLK WIRE
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BRAKE FLUID LEVEL SWITCH
BRN/BLK WIRE
CKP SENSOR SHIELD
CKP/TDC SENSOR SHIELD
CONDENSER FAN MOTOR
COUNTERSHAFT SPEED SENSOR SHIELD
CRUISE CONTROL ACTUATOR
CYP SENSOR SHIELD
CYP/TDC SENSOR SHIELD
DATA LINK CONNECTOR
ENGINE CONTROL MODULE
ENGINE COOLANT TEMPERATURE SWITCH A
ENGINE COOLANT TEMPERATURE SWITCH B
ENGINE MOUNT BRACKET
FOG LIGHT SYSTEM CONNECTOR
HEATED OXYGEN SENSOR SHIELD
KNOCK SENSOR SHIELD
LEFT FRONT FENDER)
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT ASSEMBLY
MAINSHAFT SPEED SENSOR SHIELD
MAINSHAFT/ COUNTERSHAFT SPEED SENSOR SHIELD
POWER STEERING PRESSURE SWITCH
PROGRAMMED FUEL INJECTION MAIN RELAY
RADIATOR FAN MOTOR
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT ASSEMBLY
TRANSMISSION
TRANSMISSION CONTROL MODULE
VALVE COVER)
VEHICLE SPEED SENSOR
VTEC PRESSURE SWITCH
WINDSHIELD INTERMITTENT WIPER RELAY
WINDSHIELD WASHER MOTOR
WINDSHIELD WIPER MOTOR
Go to component: -> Ground distribution circuit (1 of 4) -> LEFT FRONT TURN SIGNAL LIGHT
