Honda Prelude IV (1992-1996) int wipe input Wiring diagram
This page shows the only wiring diagram for the component.int wipe input, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram int wipe input (1 of 1)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
FUSE 17
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GROUND
HOT IN ON OR START
INT LO
INT WIPE INPUT
INTEGRATED CONTROL UNIT
INTERMITTENT WIPER CIRCUIT
LEFT FRONT FENDER)
MIST
OFF
PARK
PARK INPUT
RUN WIRE
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
WASH
WASHER ON INPUT
WIND- SHIELD WIPER/ WASHER SWITCH
WINDSHIELD WASHER MOTOR (BEHIND LOWER LEFT FRONT BUMPER FASCIA)
WINDSHIELD WIPER INTERMITTENT RELAY (LEFT REAR CORNER OF ENGINE COMPARTMENT)
WINDSHIELD WIPER MOTOR (BEHIND LEFT SIDE OF AIR SCOOP)
WIPE INT CTRL
