Honda Prelude IV (1992-1996) hot in on underdash fuse/relay box fuse 9 Wiring diagram

This page shows the only wiring diagram for the component.hot in on underdash fuse/relay box fuse 9, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram hot in on underdash fuse/relay box fuse 9 (1 of 1)

Wiring diagram hot in on underdash fuse/relay box fuse 9 for Honda Prelude IV (1992-1996)

Get access

1994 VFTC AIR CONDITIONING SYSTEM (CONDENSER FAN CONTROLS) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE ENGINE CONTROL MODULE (RIGHT FRONT OF FLOOR) FUSE 45 CONDENSER FAN FUSE 47 COOLING FAN HOT AT ALL TIMES HOT IN ON OR START SRS FUSE BLOCK FUSE 23 HOT IN ON UNDERDASH FUSE/RELAY BOX FUSE 9 J/C RADIATOR FAN CONTROL MODULE (RIGHT FRONT OF FLOOR) RADIATOR FAN MOTOR (RIGHT FRONT OF ENGINE COMPT) RADIATOR FAN RELAY RED WIRE UNDERHOOD FUSE/RELAY BOX W/ A/C WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/WHT WIRE

Go to component: -> Cooling fan circuit -> HOT IN ON UNDERDASH FUSE/RELAY BOX FUSE 9
