Honda Prelude IV (1992-1996) fuse 35 heater motor Wiring diagram
This page shows the only wiring diagram for the component.fuse 35 heater motor, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuse 35 heater motor (1 of 1)
ABS CONTROL UNIT
ABS PUMP MOTOR RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU/RED WIRE
BRAKE SWITCH HORN RELAY
DAYTIME RUNNING LIGHTS CONTROL UNIT (CANADA)
ELECTRICAL LOAD DETECTOR (ELD) UNIT
FOG LIGHT SYSTEM CONNECTOR
FROM FUSE 31
FUSE 3
FUSE 31 ABS MOTOR
FUSE 32 BATTERY
FUSE 34 REAR DEFROSTER
FUSE 35 HEATER MOTOR
FUSE 36 FUSE BOX
FUSE 37 POWER WINDOW
FUSE 38
FUSE 39 HAZARD
FUSE 4
FUSE 40
FUSE 41 STOP/HORN
FUSE 49
FUSE 6
FUSE 7
FUSE 8
HAZARD WARNING SWITCH
JUNCTION CONNECTOR 7 (BEHIND LEFT SIDE OF DASH)
PGM-FI MAIN RELAY
POWER WINDOW RELAY
REAR WINDOW DEFOGGER RELAY BLOWER MOTOR RELAY
RED/GRN WIRE
RIGHT HORN LEFT HORN
SEAT HEATER MAIN RELAY (CANADA)
STARTER
SUNROOF CLOSE RELAY
SUNROOF OPEN RELAY
TO FUSE 33
TO FUSE 38
TURN SIGNAL/ HAZARD RELAY
UNDERDASH FUSE/RELAY BOX
UNDERHOOD FUSE/RELAY BOX
UNIT)
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BLU WIRE
Go to component: -> Power distribution circuit (1 of 5) -> FUSE 35 HEATER MOTOR
