Honda Prelude IV (1992-1996) fuel gauge in Wiring diagram

* W/ ELECTRO- LUMINESCENT GAUGE OPTION ONLY ABS INDIC ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BRAKE LAMP BRAKE WARNING BRN WIRE CANADA ONLY CHARGE INDIC CHECK ENGINE CLOCK COOLANT TEMP DIMMING INPUT DIMMING INPUT CRUISE CONTROL SYSTEM ENGINE CONTROLS SYSTEM CRUISE INDIC DOOR INDIC DRL INDIC FUEL GAUGE IN FUEL GAUGE/ ENGINE COOLANT TEMPERATURE (ECT) GAUGE CIRCUIT (ELECTRONIC DISPLAY) FUSE 13 FUSE 2 GRN/BLK WIRE GRN/BLU WIRE GRN/RED WIRE GRN/WHT WIRE GROUND ILLUM INPUT ILLUM OUT * IGNITION BATTERY HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM STARTING/CHARGING SYSTEM INTERIOR LIGHTS SYSTEM HOT IN ON OR START HOT IN START IGNITION IN GROUND ILLUM OUT * GROUND LEFT BRAKE LIGHT FAILURE SENSOR (BEHIND LEFT TAILLIGHT ASSEMBLY) LOW FUEL LT GRN WIRE NCA WIRE OIL PRESS INDIC RED WIRE RED/BLK WIRE RED/BLU WIRE SEAT BELT INDIC SUB GAUGE ASSEMBLY TIME SET SWITCH (NEAR SUB- GAUGE ASSEMBLY) TO MAIN GAUGE ASSEMBLY (W/ ELECTRO- LUMINESCENT CLUSTER) TRUNK INDIC UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) WARNING SYSTEMS INTERIOR LIGHTS SYSTEM WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE YEL/WHT WIRE
