Honda Prelude IV (1992-1996) from headlight splice below wiring diagram
This page shows the only wiring diagram for the component.from headlight splice below, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
from headlight splice below wiring diagram (1 of 1)
BLK WIRE
BLU/RED WIRE
COMBINATION LIGHT SWITCH
DIMMER RELAY
DIMMER SWITCH
FLASH TO PASS SWITCH
FOG LIGHT CONNECTOR
FROM HEADLIGHT SPLICE BELOW
FUSE 32
FUSE 50
FUSE 51
HEAD OFF PARK
HEADLIGHT RELAY
HEADLIGHT SWITCH
HOT AT ALL TIMES
LEFT FRONT FENDER)
LEFT HEADLIGHT (HIGH)
LO HI
MAIN GAUGE ASSEMBLY HIGH BEAM INDICATOR LIGHT
NCA WIRE
ORG/ WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT HEADLIGHT (LOW)
TO UNNDER-HOOD FUSE/RELAY BOX
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX
WIPER/WASHER SYSTEM
Go to component -> Headlamps circuit, without drl -> FROM HEADLIGHT SPLICE BELOW
