Honda Prelude IV (1992-1996) engine controls, transmissions systems Wiring diagram
This page shows the only wiring diagram for the component.engine controls, transmissions systems, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine controls, transmissions systems (1 of 1)
A/T GEAR POSITION SWITCH (UNDER CENTER CONSOLE)
BLK WIRE
BLK/YEL WIRE
BLU WIRE
CRUISE CONTROL SYSTEM
ENGINE CONTROLS SYSTEM
ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
FUSE 13
FUSE 23
GRN WIRE
GRN/BLU WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADLIGHTS SYSTEM
HIGH BEAM
HOT IN ON OR START
IGNITION CONTROL MODULE (ICM) (TOP RIGHT SIDE OF ENGINE, IN DISTRIBUTOR)
ILLUMINATION
LEFT TURN
LT GRN WIRE
LT GRN/WHT WIRE
MAIN GAUGE ASSEMBLY
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
RIGHT TURN
SPEEDOMETER/ ODOMETER
SRS FUSE BLOCK
SRS INDIC
SRS INDICATOR DRIVER, DIMMER CONTROL CIRCUITS
SUPPLEMENTAL RESTRAINTS SYSTEM
TACH TEST CONNECTOR (RIGHT SIDE OF ENGINE COMPARTMENT)
TACHOMETER
TRANSMISSIONS SYSTEM
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
VEHICLE SPEED SENSOR (VSS) (RIGHT SIDE OF TRANSMISSION)
YEL WIRE
Go to component: -> Sub gauge assembly circuit, without electro-luminescent gauges -> ENGINE CONTROLS, TRANSMISSIONS SYSTEMS
