Honda Prelude IV (1992-1996) engine control system Wiring diagram
This page shows the only wiring diagram for the component.engine control system, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram engine control system (1 of 1)
A/T GEAR POSITION SWITCH
BLK WIRE
BLU WIRE
BRAKE SWITCH (LEFT I/P)
CRUISE CONTROL SYSTEM
ENGINE CONTROL SYSTEM
FUSE 41 FUSE 46
GRN WIRE
GRN/ WHT WIRE
GRN/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 13
INTERLOCK CONTROL UNIT (RIGHT SIDE OF I/P)
J/C
KEY INTERLOCK SOLENOID
KEY INTERLOCK SWITCH
RED WIRE
RED/BLK WIRE
SHIFT LOCK SOLENOID (RIGHT SIDE OF FRONT CONSOLE)
THROTTLE POSITION SENSOR CENTER REAR OF ENGINE)
TRANSMISSION CONTROL MODULE (RIGHT FRONT FLOOR)
TRANSMISSION SYSTEM
UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL)
UNDER-HOOD FUSE/RELAY BOX (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
WHT GRN/ WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Shift interlock circuit -> ENGINE CONTROL SYSTEM
