Honda Prelude IV (1992-1996) dash sensor Wiring diagram
This page shows the only wiring diagram for the component.dash sensor, which is found in the car Honda Prelude IV (1992-1996). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram dash sensor (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (TOP OF STEERING COLUMN)
COWL SENSOR
DASH SENSOR
DATA LINK CONNECTOR (BEHIND FRONT CONSOLE)
DRIVER'S AIRBAG INFLATOR
FRONT PASSENGER'S AIRBAG INFLATOR (RIGHT SIDE OF I/P)
FUSE 24
GAUGE ASSEMBLY
GRY WIRE
HOT IN ON OR START SRS FUSE BLOCK (LEFT KICK PANEL) FUSE 23
HOT IN ON OR START UNDER-DASH FUSE/RELAY BOX (LEFT KICK PANEL) FUSE 13
INDICATOR CIRCUIT
LT GRN WIRE
MONITOR CIRCUIT
NCA WIRE
RED WIRE
SERVICE CHECK CONNECTOR (BEHIND FRONT CONSOLE)
SRS INDICATOR
SRS MEMORY ERASE SIGNAL CONNECTOR
SRS UNIT (BELOW CENTER OF I/P)
STEERING WHEEL)
WHT WIRE
YEL WIRE
Go to component: -> Supplemental restraint circuit -> DASH SENSOR
