Honda Prelude IV (1992-1996) bi-lev switch Wiring diagrams

This page contains all the electrical diagrams for the component. bi-lev switch, in which he is found in the car Honda Prelude IV (1992-1996). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram bi-lev switch (1 of 2)

Wiring diagram bi-lev switch for Honda Prelude IV (1992-1996)

Get access

1995 VFTC A/C SWITCH BI-LEV SWITCH BLK WIRE BLK/YEL WIRE BLOWER MOTOR RELAY BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE DEFROST SWITCH DIMMING CIRCUIT ENGINE OR POWERTRAIN CONTROL MODULE (RIGHT FRONT FLOOR, UNDER CARPET) FRESH FUSE 11 FUSE 9 GRN WIRE GRN/RED WIRE GRN/WHT WIRE HEAT SWITCH HEAT/DEF SWITCH HEATER CONTROL PANEL HOT IN ON HOT IN ON OR START J/B J/C (1996) LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE OFF OFF HEATER FAN SWITCH RECIRC RECIRC FRESH/ RECIRC SWITCH FRESH RED WIRE RED/BLK WIRE RED/BLU WIRE TRANSMISSION CONTROLS SYSTEM UNDER-DASH FUSE/RELAY BOX VENT SWITCH WHT WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component: -> A/c circuit (1 of 2) -> BI-LEV SWITCH

Wiring diagram bi-lev switch (2 of 2)

Wiring diagram bi-lev switch for Honda Prelude IV (1992-1996)

Get access

1995 VFTC BI-LEV SWITCH BLK WIRE BLK/YEL WIRE BLOWER MOTOR BLOWER MOTOR RELAY BLOWER RESISTOR (BEHIND GLOVE BOX) BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN/WHT WIRE DEFROST SWITCH DIMMING CIRCUIT FRESH FUSE 36 HEATER MOTOR FUSE 9 GRN/RED WIRE GRN/WHT WIRE HEAT SWITCH HEAT/DEF SWITCH HEATER CONTROL PANEL HEATER FAN SWITCH HOT AT ALL TIMES HOT IN ON J/B J/B (1996) LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/WHT WIRE MODE CONTROL MOTOR (BELOW I/P, RIGHT OF STEERING COLUMN) OFF RECIRC RECIRC FRESH/ RECIRC SWITCH FRESH RECIRCULATION CONTROL MOTOR (BEHIND GLOVE BOX) RED WIRE RED/BLK WIRE UNDER-DASH FUSE/RELAY BOX VENT SWITCH WHT WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component: -> Heater circuit -> BI-LEV SWITCH
