Car Wiring Diagrams for Body control modules circuit for Honda Pilot III facelift (2018-2022)

AUXILIARY UNDER-DASH FUSE/RELAY BOX BLK WIRE BLU WIRE BRN WIRE DIODE A DIODE B DOOR LOCKS, ANTI-THEFT SYSTEMS FUSE 16 FUSE 21 FUSE 22 FUSE 26 FUSE 29 FUSE 37 FUSE 38 FUSE 4 GRN WIRE GRY WIRE HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES HOT W/ ACC RELAY ENERGIZED HOT W/ DC-DC JOINT 7 JOINT 8 LT BLU WIRE MEMORY SYSTEMS MICU PNK WIRE POWER DISTRIBUTION SYSTEM POWER WINDOWS SYSTEM PPL RED WIRE RELAY 2 ENERGIZED RELAY ENERGIZED REVERSE RELAY TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) UNDER-HOOD FUSE/RELAY BOX WHT WIRE WIPER/ WASHER SYSTEM YEL WIRE

BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM EXTERIOR LIGHTS, INTERIOR LIGHTS SYSTEMS GRN WIRE GRY WIRE HEADLIGHTS SYSTEM LT BLU WIRE LT GRN WIRE MICU PNK WIRE PPL RED WIRE SEATS SYSTEM TAN WIRE TRUNK, TAILGATE, FUEL DOORS SYSTEM UNDER-DASH FUSE/RELAY BOX (LEFT END OF DASH) WHT WIRE YEL WIRE
