Honda Pilot III facelift (2018-2022) left one-touch access switch Wiring diagram
This page shows the only wiring diagram for the component.left one-touch access switch, which is found in the car Honda Pilot III facelift (2018-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left one-touch access switch (1 of 1)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
DOOR
DOOR LOCK
DOOR OFF
DRIVER'S DOOR INNER HANDLE LIGHT
DRIVER'S DOOR LOCK ACTUATOR/ KNOB SWITCH/KEY CYLINDER SWITCH
DRIVER'S DOOR LOCK KNOB SWITCH
DRIVER'S DOOR POCKET LIGHT
DRIVING POSITION MEMORY SWITCH
FRONT PASSENGER'S DOOR INNER HANDLE LIGHT
FRONT PASSENGER'S DOOR POCKET LIGHT
GRN WIRE
GRY WIRE
JOINT 8
KEY
KNOB
LEFT ONE-TOUCH ACCESS SWITCH
LEFT REAR DOOR INNER HANDLE LIGHT
LEFT REAR DOOR POCKET LIGHT
LEFT REAR POWER WINDOW SWITCH
LT BLU WIRE
LT GRN WIRE
OFF
OPTION CONNECTOR A
POWER WINDOW MASTER SWITCH
PPL
RIGHT END OF DASH)
RIGHT ONE-TOUCH ACCESS SWITCH
RIGHT REAR DOOR INNER HANDLE LIGHT
RIGHT REAR DOOR POCKET LIGHT
RIGHT REAR POWER WINDOW SWITCH
TAN WIRE
W/ BLIND SPOT MONITORING
W/ PANORAMIC GLASS ROOF
W/O BLIND SPOT MONITORING
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (3 of 3) -> LEFT ONE-TOUCH ACCESS SWITCH
