Honda Pilot III (2015-2018) Compass circuit

Compass circuit

Car Wiring Diagrams for Pilot Honda III (2015-2018): Compass circuit

AUDIO UNIT BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM ELECTRICAL COMPASS UNIT FUSE 29 GRN WIRE HOT AT ALL TIMES PNK WIRE PPL RELAY ENERGIZED TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE
