Car Wiring Diagrams for Headlamps leveling circuit for Honda Pilot III (2015-2018)

AUTOMATIC LIGHTING SENSOR AUTOMATIC LIGHTING/ RAIN SENSOR B-CAN H B-CAN L B-CAN TRANSCEIVER BLK WIRE BRN WIRE COMBINATION LIGHT SWITCH COMPUTER DATA LINES SYSTEM DIMMER/ FLASH-TO- PASS SWITCH DRIVE CIRCUIT FRONT SUSPENSION STROKE SENSOR FUSE 26 FUSE 28 GAUGE CONTROL MODULE GRN WIRE HEADLIGHT LEVELING CONTROL UNIT HEADLIGHT SWITCH 0) OFF 1) PARK 2) AUTO 3) HEAD HOT AT ALL TIMES LEFT HEADLIGHT LEVELING MOTOR LT BLU WIRE LT GRN WIRE MICROPROCESSOR (CAN X 2 CHANNEL) MICU PASSING PNK WIRE PPL REAR SUSPENSION STROKE SENSOR RED WIRE REGULATOR RELAY ENERGIZED RIGHT END OF DASH) RIGHT HEADLIGHT LEVELING MOTOR TAN WIRE UNDER-DASH FUSE/RELAY BOX UNDER-HOOD FUSE/RELAY BOX WHT WIRE YEL WIRE
