Car Wiring Diagrams for Backup lamps circuit for Honda Pilot III (2015-2018)

AUDIO UNIT AUDIO- NAVIGATION UNIT AUTOMATIC DIMMING INSIDE MIRROR BLK WIRE BLU WIRE BRN WIRE DIODE A DIODE B FUSE 29 LEFT BACKUP LIGHT MICU OPTIONAL CONNECTOR A PCM RELAY ENERGIZED REVERSE RELAY RIGHT BACKUP LIGHT TRANSMISSION CONTROL MODULE TRANSMISSION RANGE SWITCH UNDER-DASH FUSE/RELAY BOX W/ NAVIGATION W/ REAR SEAT ENTERTAINMENT WHT WIRE
