Honda Pilot III (2015-2018) warning indicator drive circuit Wiring diagrams
This page contains all the electrical diagrams for the component. warning indicator drive circuit, in which he is found in the car Honda Pilot III (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram warning indicator drive circuit (11 of 13)
ABS IND.
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION SWITCH
BRAKE SYSTEM IND
BRAKE WARNING IND
BRN WIRE
CMBS SWITCH
COMPUTER DATA LINES SYSTEM
DIMMIMG CIRCUIT
ECO IND
ECON SWITCH
F-CAN
F-CAN H
F-CAN L
FUSE 1
FUSE 2
FUSE 29
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ DC-DC
KEYLESS ACCESS/TPMS CONTROL UNIT
MICROPROCESSOR (CAN X 2 CHANNEL)
MICU
PARKING BRAKE SWITCH
PCM
PNK WIRE
PPL
RED WIRE
RELAY 1 ENERGIZED
RELAY 2 ENERGIZED
RELAY ENERGIZED
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
VSA IND
VSA OFF IND
VSA OFF SWITCH
VSA OFF/ CMBS OFF SWITCH
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
W/ CMBS
W/ CMBS W/O CMBS
W/O CMBS
W/O CMBS W/ CMBS
WARNING INDICATOR DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> WARNING INDICATOR DRIVE CIRCUIT
Wiring diagram warning indicator drive circuit (12 of 13)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL COMBINATION SWITCH/ ACC COMBINATION SWITCH
ENGINE MOUNT CONTROL UNIT
F-CAN H
F-CAN L
F-CAN TRANSCEIVER
FCW IND
FUSE 1
FUSE 26
FUSE 28
FUSE 29
FUSE 3
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
LDW IND
LKAS IND
LKAS SWITCH
LT BLU WIRE
LT GRN WIRE
MICROPROCESSOR (CAN X 2 CHANNEL)
MILLIMETER WAVE RADAR
MULTI-PURPOSE CAMERA UNIT
PNK WIRE
PPL
RDM OFF SWITCH
RED WIRE
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WARNING INDICATOR DRIVE CIRCUIT
WHT WIRE
Go to component -> Multipurpose camera circuit -> WARNING INDICATOR DRIVE CIRCUIT
Wiring diagram warning indicator drive circuit (13 of 13)
AMP
AUXILIARY UNDER-DASH FUSE/RELAY BOX
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
CONTROL UNIT)
FUSE 1
FUSE 26
GAUGE CONTROL MODULE
GRN WIRE
HOT AT ALL TIMES
HOT W/ DC-DC
IMMOBILIZER INDICATOR
KEYLESS ACCESS SYSTEM INDICATOR
MICROPROCESSER (CAN * 2 CHANNEL)
MICU
MULTI-INFORMATION DISPLAY (MID)
PCM
PNK WIRE
PPL
RED WIRE
REGULATOR
RELAY 1 ENERGIZED
SECURITY INDICATOR
SPEAKER
TAN WIRE
TPMS INDICATOR
UNDER-HOOD FUSE/RELAY BOX
WARNING INDICATOR DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Power door locks circuit (5 of 7) -> WARNING INDICATOR DRIVE CIRCUIT
