Honda Pilot III (2015-2018) vsa off/ cmbs off switch Wiring diagrams
This page contains all the electrical diagrams for the component. vsa off/ cmbs off switch, in which he is found in the car Honda Pilot III (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram vsa off/ cmbs off switch (1 of 3)
ABS IND.
AUXILIARY UNDER-DASH FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SWITCH
BRAKE PEDAL POSITION SWITCH
BRAKE SYSTEM IND
BRAKE WARNING IND
BRN WIRE
CMBS SWITCH
COMPUTER DATA LINES SYSTEM
DIMMIMG CIRCUIT
ECO IND
ECON SWITCH
F-CAN
F-CAN H
F-CAN L
FUSE 1
FUSE 2
FUSE 29
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT W/ DC-DC
KEYLESS ACCESS/TPMS CONTROL UNIT
MICROPROCESSOR (CAN X 2 CHANNEL)
MICU
PARKING BRAKE SWITCH
PCM
PNK WIRE
PPL
RED WIRE
RELAY 1 ENERGIZED
RELAY 2 ENERGIZED
RELAY ENERGIZED
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
VSA IND
VSA OFF IND
VSA OFF SWITCH
VSA OFF/ CMBS OFF SWITCH
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
W/ CMBS
W/ CMBS W/O CMBS
W/O CMBS
W/O CMBS W/ CMBS
WARNING INDICATOR DRIVE CIRCUIT
WHT WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 2) -> VSA OFF/ CMBS OFF SWITCH
Wiring diagram vsa off/ cmbs off switch (2 of 3)
AUTOMATIC A/C
BLK WIRE
CD PLAYER UNIT (IF EQUIPPED)
CLIMATE CONTROL UNIT
DRIVER'S VENTILATED SEAT HEATER SWITCH
DVD PLAYER UNIT
ECON SWITCH
FRONT CONSOLE BOX LIGHT
FRONT PASSENGER'S VENTILATED SEAT HEATER SWITCH
GLOVE BOX LIGHT
GRY WIRE
HAZARD WARNING SWITCH/FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
HEATED WINDSHIELD WIPER AREA/PARKING, BACKUP SENSOR SWITCH
HVAC CONTROL UNIT
IDLE STOP OFF SWITCH
MANUAL A/C
PARKING, BACK-UP SENSOR SWITCH
POWER MIRROR SWITCH
RDF OFF SWITCH
RED WIRE
RIGHT END OF DASH)
SBW SHIFTER CONTROL MODULE
VSA OFF SWITCH
VSA OFF/ CMBS OFF SWITCH
Go to component -> Instrument illumination circuit (3 of 3) -> VSA OFF/ CMBS OFF SWITCH
Wiring diagram vsa off/ cmbs off switch (3 of 3)
