Honda Pilot III (2015-2018) dc-dc converter Wiring diagrams
This page contains all the electrical diagrams for the component. dc-dc converter, in which he is found in the car Honda Pilot III (2015-2018). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram dc-dc converter (1 of 14)
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER-DASH RELAY HOLDER A
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
DC-DC CONVERTER
ELECTRIC STEERING LOCK (IF EQUIPPED)
FUSE 1-5
FUSE 1-6
FUSE 10
FUSE 14
FUSE 2
FUSE 3
FUSE 6
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
KEYLESS ACCESS/TPMS CONTROL UNIT (IF EQUIPPED) (RIGHT SIDE OF DASH)
KEYLESS/POWER TAILGATE OUTSIDE BUZZER
LT BLU WIRE
LT GRN WIRE
MICU
PNK WIRE
PPL
REAR WINDOW WIPER MOTOR RELAY
RED WIRE
RIGHT END OF DASH)
STEERING ANGLE SENSOR
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/O DC-DC CONVERTER W/ DC-DC CONVERTER
WHT WIRE
YEL WIRE
Go to component -> Anti-theft circuit (3 of 7) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (2 of 14)
6 SPEED A/T
ALTERNATOR
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BATTERY
BATTERY SENSOR
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL (9 SPEED A/T)
CHARGING SYSTEM INDICATOR
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DRIVE CIRCUIT
F-CAN
F-CAN H
F-CAN L
FUSE 1
FUSE 1-6
FUSE 13
FUSE 14
FUSE 29
FUSE 4
FUSE 7
GAUGE CONTROL MODULE
GRN WIRE
HEATED STEERING WHEEL CONTROL UNIT
HOT W/
HOT W/ DC-DC
INDICATOR
MICROPROCESSOR
PCM
RED WIRE
RELAY 1 ENERGIZED
STARTER
TAN WIRE
TRANSCEIVER/
UNDER- DASH FUSE/ RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WARNING
WHT WIRE
YEL WIRE
Go to component -> Charging circuit -> DC-DC CONVERTER
Wiring diagram dc-dc converter (3 of 14)
6 SPEED A/T
APP SENSOR
APP SENSOR A
APP SENSOR B
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
FUSE 14
FUSE 2
FUSE 21
FUSE 6
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ DC-DC CONVERTER
KEYLESS ACCESS/ TPMS CONTROL UNIT
LINES SYSTEM
LT BLU WIRE
LT GRN WIRE
OUTPUT SHAFT (COUNTERSHAFT) SPEED SENSOR
PCM
PGM-FI MAIN RELAY 1
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RELAY CIRCUIT BOARD
TAN WIRE
THROTTLE ACTUATOR
THROTTLE BODY (RIGHT REAR OF ENGINE)
THROTTLE OPEN SENSOR
TRANSMISSION CONTROL MODULE
TRANSMISSION RANGE SWITCH
UNDER-HOOD FUSE/RELAY BOX
VSA MODULATOR CONTROL UNIT
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
WHT WIRE
YEL WIRE
Go to component -> Cruise control circuit (1 of 2) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (4 of 14)
AUTO
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
FUSE 14
FUSE 21
FUSE 27
FUSE 4
FUSE 6
FUSE 7
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HEADLIGHTS SYSTEM
HOT AT ALL TIMES
HOT W/
LEFT
LEFT FRONT TURN SIGNAL LIGHT
LEFT POWER MIRROR
LEFT REAR TURN SIGNAL LIGHT
LEFT TAILLIGHT
LT GRN WIRE
MICU
OFF
OPTIONAL CONNECTOR A
ORG/ WIRE
PARK
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
RELAY CIRCUIT BOARD
RIGHT
TAILLIGHT RELAY
TAN WIRE
TURN SIGNAL SWITCH
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
W/ AUTO IDLE STOP SYSTEM W/O AUTO IDLE STOP SYSTEM
WHT WIRE
Go to component -> Exterior lamps circuit (1 of 3) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (5 of 14)
AM/FM ANTENNA AMPLIFIER
AUDIO- NAVIGATION UNIT
AUTO HIGH BEAM CONTROL UNIT
AUTOMATIC DIMMING INSIDE MIRROR
AUTOMATIC LIGHTING/RAIN SENSOR
BATTERY FAN
BLK WIRE
BRAKE FLUID LEVEL SWITCH
BRN WIRE
CARGO AREA ACCESSORY POWER SOCKET RELAY
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DIODE C
DRIVER'S VANITY MIRROR LIGHT
ELECTRIC STEERING LOCK
ELECTRICAL COMPASS UNIT
EPS CONTROL UNIT
FRONT INDIVIDUAL MAP LIGHT
HEATED WINDSHIELD WIPER AREA
HOMELINK UNIT
MEDIA HUB UNIT
MOONROOF/ INTERIOR LIGHT SWITCH
MULTI-PURPOSE CAMERA UNIT
PASSENGER'S VANITY MIRROR LIGHT
POWER DOOR LOCK RELAY (DOOR UNLOCK)
POWER DOOR LOCK RELAY (LOCK)
POWER DOOR LOCK RELAY (UNLOCK)
ROOF CONSOLE MODULE
TAILGATE RELEASE ACTUATOR RELAY
TUNER UNIT
W/ PANORAMIC GLASS ROOF
WINDSHIELD WIPER MOTOR
Go to component -> Ground distribution circuit (5 of 8) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (6 of 14)
AUTO
AUTOMATIC LIGHTING SENSOR
AUTOMATIC LIGHTING/ RAIN SENSOR
AUXILIARY UNDER-DASH FUSE/RELAY BOX
B-CAN
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DIMMING CIRCUIT
DRIVE CIRCUIT
FUSE 1
FUSE 25
FUSE 26
FUSE 4
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEAD
HEADLIGHT SWITCH
HOT AT ALL TIMES
HOT W/ DC-DC
ILLUMINATION CONTROL
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR AMBIENT ECO
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR DIAL FACE (WHITE)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR LCD (SPEEDOMETER)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR POINTER (WHITE)
ILLUMINATION CONTROL, DIMMING CIRCUIT FOR TFT (MID)
LIGHTS ON IND
LT BLU WIRE
MICROPROCESSOR (CAN * 2 CHANNEL)
MICU
OFF
OFF PARK
PARK
PNK WIRE
PPL
RED WIRE
RELAY 1 ENERGIZED
RELAY CIRCUIT BOARD
TAILLIGHT RELAY
TAN WIRE
TRANSCEIVER/
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WARNING/ INDICATOR
WHT WIRE
Go to component -> Instrument illumination circuit (1 of 3) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (7 of 14)
19-PIN CONNECTOR
6 PIN CONNECTOR
AUDIO UNIT (W/O NAVIGATION) AUDIO- NAVIGATION UNIT (W/ NAVIGATION)
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLK/LT BLU WIRE
BLU WIRE
COMBINATION LIGHT SWITCH
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
FUSE 13
FUSE 29
FUSE 5
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LANE WATCH CAMERA
LANE WATCH SWITCH
ORG/ WIRE
ORG/BLK WIRE
PPL
RED WIRE
RIGHT POWER MIRROR
TAN WIRE
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Lane watch camera circuit -> DC-DC CONVERTER
Wiring diagram dc-dc converter (8 of 14)
AUDIO REMOTE SWITCH
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
CABLE REEL
CH-
COMPUTER DATA LINE SYSTEM
DC-DC CONVERTER
DC-DC CONVERTER ACC RELAY
DISPLAY CHANGE
DOOR LOCKS SYSTEM
FUSE 13
FUSE 5
FUSE 6
FUSE 7
GRN WIRE
GRY WIRE
HANG-UP/ BACK
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
MENU
ORG/ WIRE
PICK-UP
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL
RED WIRE
SOURCE
TALK
TAN WIRE
VOLUME DOWN
VOLUME UP
W/ HEATED STEERING WHEEL
W/O HEATED STEERING WHEEL
WHT WIRE
YEL WIRE
Go to component -> Navigation circuit, w/ amplifier (1 of 8) -> DC-DC CONVERTER
Wiring diagram dc-dc converter (9 of 14)
AUDIO UNIT (W/O NAVIGATION)
AUDIO- NAVIGATION UNIT
AUXILIARY UNDER-DASH FUSE/RELAY BOX
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRN WIRE
DC-DC CONVERTER
FUSE 14
FUSE 40
FUSE 7
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
POWER DISTRIBUTION SYSTEM
PPL
REAR VIEW CAMERA
RED WIRE
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
W/ DC-DC CONVERTER ACC RELAY
W/ NAVIGATION
W/ NAVIGATION, W/O NAVIGATION DISPLAY AUDIO
W/O NAVIGATION COLOR AUDIO
WHT WIRE
Go to component -> Rear camera circuit -> DC-DC CONVERTER
Wiring diagram dc-dc converter (10 of 14)
APP SENSOR
APP SENSOR A
APP SENSOR B
AUXILIARY UNDER-HOOD FUSE/RELAY BOX
BLK WIRE
BLU WIRE
BRAKE LIGHT RELAY
BRAKE PEDAL POSITION SWITCH
BRN WIRE
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
FUSE 14
FUSE 15
FUSE 29
FUSE 6
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
PCM
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SBW SHIFTER CONTROL MODULE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Shift interlock circuit, 9 speed a/t -> DC-DC CONVERTER
