Honda Pilot III (2015-2018) 12 volt battery sensor Wiring diagram
This page shows the only wiring diagram for the component.12 volt battery sensor, which is found in the car Honda Pilot III (2015-2018). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 12 volt battery sensor (1 of 1)
12 VOLT BATTERY SENSOR
AUXILIARY UNDER-DASH RELAY HOLDER A
B-CAN H
B-CAN L
B-CAN TRANSCEIVER
BLK WIRE
BLU WIRE
CABLE REEL (IN STEERING COLUMN)
COMPUTER DATA LINES SYSTEM
FUSE 23
FUSE 26
FUSE 27
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL UNIT
HEATED STEERING WHEEL RELAY
HEATER PAD
HFL-NAVIGATION VOICE CONTROL SWITCH/ HEATED STEERING WHEEL SWITCH
HOT AT ALL TIMES
LIN TRANSCEIVER
LT GRN WIRE
MICROPROCESSOR (CAN * 2 CHANNEL)
PNK WIRE
PPL
RED WIRE
RELAY ENERGIZED
TAN WIRE
UNDER-DASH FUSE/RELAY BOX
UNDER-HOOD FUSE/RELAY BOX
WHT WIRE
Go to component -> Heated steering wheel circuit -> 12 VOLT BATTERY SENSOR
