Parking assistant circuit, honda accessory for Honda Pilot II facelift (2011-2015)
Parking assistant circuit, honda accessory
4 5 6 7 8 9 10 11 12 13 R CORNER SENS L CORNER SENS BACK LT OUT GROUND RR SENS
A/T REVERSE RELAY
BACKUP SENSOR BEEPER ASSEMBLY
BACKUP SENSOR BEEPER SWITCH
BACKUP SENSOR IN LINE FUSE
BACKUP SENSOR SYSTEM CONNECTOR
BACKUP SENSOR SYSTEM JUNCTION CONNECTOR
BEEPER (+) R BACK SENS L BACK SENS
BLK WIRE
BLU WIRE
FUSE 10
HOT IN ON OR START
J/C
LEFT CENTER BACKUP SENSOR
LEFT CORNER BACKUP SENSOR
NCA WIRE
ON INDICATOR
ORG/ WIRE
ORG/RED WIRE
PARKING, BACKUP SENSOR CONTROL UNIT (UNDER LEFT SIDE OF DASH)
PNK WIRE
RED WIRE
RIGHT CENTER BACKUP SENSOR
RIGHT CORNER BACKUP SENSOR
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH) MICU
W/O POWER TAILGATE W/ POWER TAILGATE
WHT WIRE
YEL WIRE
YEL/RED WIRE
