Honda Pilot II facelift (2011-2015) rrr ctr gnd wiring diagram
This page shows the only wiring diagram for the component.rrr ctr gnd, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rrr ctr gnd wiring diagram (1 of 1)
2 4 6 1 3 5 PNK SOR CTRL BOR CTRL RRR CTR GND RRR CTR SIG RRR CTR + WIRE
2 4 6 5 3 1 RRL GND RRL SIG RRL + BOR CTRL SOR CTRL
6 4 2 1 3 5 PPL RRR CTR + RRR CTR SIG RRR CTR GND RRR CTR GND RRR SIG RRR +
ATP-P
ATP-R
BEEPER
BLK WIRE
BLU WIRE
BOF SIDE R
BRN WIRE
CAN H CAN L ATPP ATPR
COMPUTER DATA LINES SYSTEM
ENGINE COMPT)
FAST CONTROLLER AREA
FRL
FRL + RRL + PPL
FRL GND
FRL SIG
FRONT PARKING SENSOR BEEPER
FUSE 23
GAUGE CONTROL MODULE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START UNDER-DASH FUSE/RELAY FUSE 8 BOX (UNDER LEFT SIDE OF DASH)
INTERIOR LIGHTS
J/C
LEFT FRONT CORNER PARKING SENSOR (LEFT SIDE OF FRONT BUMPER)
LEFT REAR CENTER SENSOR
LEFT REAR CORNER PARKING SENSOR (LEFT SIDE OF REAR BUMPER)
LT BLU WIRE
LT GRN WIRE
MAIN SW FRL GND RRL GND
MICU
MULTI-INFORMATION DISPLAY (MID) UNIT MULTI-INFORMATION SWITCH
NETWORK TRANSCEIVER
ORG/ WIRE
PARKING, BACKUP SENSOR CONTROL UNIT (UNDER LEFT SIDE OF DASH)
PARKING, BACKUP SENSOR SWITCH
PARKING/ BACKUP
PCM (RIGHT SIDE OF
PNK WIRE
PPL
REAR PARKING/ BACKUP SENSOR
RED WIRE
RIGHT FRONT CORNER PARKING SENSOR (RIGHT SIDE OF FRONT BUMPER)
RIGHT REAR CENTER SENSOR
RIGHT REAR CORNER PARKING SENSOR (RIGHT SIDE OF REAR BUMPER)
RRR +
RRR CTR GND
RRR SIG
SDF SIDE R
SENSOR ON INDICATOR
SYSTEM
TOP OF TRANSMISSION)
TRANSMISSION RANGE SWITCH (TOP LEFT SIDE OF AUTOMATIC TRANSMISSION)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
W/ FACTORY INSTALLED TRAILER LIGHTING CONNECTOR
WHT WIRE
Go to component -> Parking assistant circuit, except honda accessory -> RRR CTR GND
