Honda Pilot II facelift (2011-2015) out- ref- gnd put volt Wiring diagram
This page shows the only wiring diagram for the component.out- ref- gnd put volt, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram out- ref- gnd put volt (1 of 1)
AUXILIARY UNDER-HOOD FUSE/RELAY FUSE 10 BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S POWER SEAT FRONT UP-DOWN MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT REAR UP-DOWN MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT RECLINE MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT)
DRIVER'S POWER SEAT RECLINE MOTOR/POSITION SENSOR/LUMBAR SUPPORT MOTOR CONNECTOR
DRIVER'S POWER SEAT SLIDE MOTOR/POSITION SENSOR (UNDER DRIVER'S SEAT)
FHM + SLM +
FUSE 10
FUSE 23 BOX (RIGHT SIDE OF ENGINE COMPT)
FUSE 26
FUSE 36
FUSE 9
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
HOT IN ON OR START
LT BLU WIRE
LT GRN WIRE
METER GND GND UP
MICU +B BACK
ORG/ WIRE
OUT
OUT- REF- GND PUT VOLT
PNK ATP-P WIRE
PNK RHUP REBW SLBW WIRE
PNK WIRE
POWER SEAT CONTROL UNIT (UNDER DRIVER'S SEAT)
PPL
PPL FHM(-) SLM(-)
RED WIRE
REF- GND PUT VOLT
REM(+) RHM(-) REM(-) PNK WIRE
RHDN FHDN FHUP REFW SLFW
RHM +
S- P-
SCOM
SEG
SG RESE SLSE FHSE RHSE PNK WIRE
SHIFT INTERLOCK SYSTEM
SVCC
UART B-CAN LO B-CAN HI
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY
WHT WIRE
YEL WIRE
Go to component -> Memory seat circuit (1 of 2) -> OUT- REF- GND PUT VOLT
