Honda Pilot II facelift (2011-2015) micu wiper Wiring diagram
This page shows the only wiring diagram for the component.micu wiper, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram micu wiper (1 of 1)
AUXILIARY UNDER-DASH FUSE HOLDER (UNDER LEFT SIDE OF DASH) STS FUSE
BLK WIRE
BLU WIRE
BRAKE PEDAL POSITION SWITCH
BRN WIRE
CUT RELAY (UNDER LEFT SIDE OF DASH)
ELD UNIT
FROM FUSE 4 (DIAGRAM 7 OF 9)
FROM UNDER-DASH FUSE/RELAY BOX (DIAGRAM 6 OF 9)
FRONT PASSENGER'S AIR BAG CUT-OFF INDICATOR
FUSE 1
FUSE 11 FUSE 38
FUSE 2
FUSE 22
FUSE 23
FUSE 3
FUSE 4
FUSE 8
FUSE 9
GRN WIRE
GRY WIRE
IGNITION SWITCH
IMMOBILIZER- KEYLESS CONTROL UNIT PCM
J/C
LOCK
LOCK ON
LT BLU WIRE
LT GRN WIRE
MICU FUEL FUEL PUMP PUMP
MICU PGM-FI MAIN RELAY 2
MICU WIPER
ODS
ORG/ WIRE
PARKING, BACKUP SENSOR CONTROL UNIT (IF EQUIPPED)
PCM
PNK ODS UNIT WIRE
PNK PNK WIRE
PNK WIRE
RED WIRE
REMOTE STARTING SYSTEM CONNECTOR (OPTION CONNECTOR)
SRS
SRS UNIT PCM
STARTER CUT RELAY 1
STARTER CUT RELAY 2 (UNDER UNDERDASH FUSE/RELAY BOX)
STARTING/ CHARGING SYSTEM
STRLY
TAN WIRE
TO FUSE 10 (DIAGRAM 8 OF 9)
TO FUSE 3 (DIAGRAM 7 OF 9)
TO UNDER-DASH FUSE/RELAY BOX (DIAGRAM 8 OF 9)
TOP OF TRANSMISSION)
TPMS PARKING, CONTROL BACKUP UNIT SENSOR SWITCH (IF EQUIPPED) (IF EQUIPPED)
TRANSMISSION RANGE SWITCH
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
VSA
VSA MODULATOR CONTROL UNIT
VTM-4
VTM-4 CONTROL UNIT
VTM-4 RELAY
W/ FRONT PASSENGERS POWER SEAT 8 11 W/O FRONT PASSENGERS POWER SEAT
WHT WIRE
WIPER
YAW RATE ACCELERATION SENSOR
YEL WIRE
Go to component -> Power distribution circuit (7 of 9) -> MICU WIPER
