Honda Pilot II facelift (2011-2015) left second row seat heater switch Wiring diagrams
This page contains all the electrical diagrams for the component. left second row seat heater switch, in which he is found in the car Honda Pilot II facelift (2011-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left second row seat heater switch (1 of 2)
AUXILIARY UNDER-HOOD FUSE/RELAY BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 21
FUSE 36
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON
LEFT SECOND ROW SEAT HEATER RELAY (LOW) (UNDER LEFT SECOND ROW SEAT)
LEFT SECOND ROW SEAT HEATER SWITCH
LT BLU WIRE
LT GRN WIRE
MICU
ON INDICATORS
ORG/ WIRE
PNK WIRE
RED WIRE
RIGHT SECOND ROW SEAT HEATER RELAY (LOW) (UNDER RIGHT SECOND ROW SEAT)
RIGHT SECOND ROW SEAT HEATER SWITCH
SEAT BACK HEATER LEFT SECOND ROW SEAT HEATER
SEAT BACK HEATER RIGHT SECOND ROW SEAT HEATER
SEAT CUSHION HEATER
SWITCH ILLUMINATION
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
Go to component -> Heated seats circuit, heated second row seats -> LEFT SECOND ROW SEAT HEATER SWITCH
Wiring diagram left second row seat heater switch (2 of 2)
2 3 W/ MEMORY W/O MEMORY
7 17 W/O MOONROOF W/ MOONROOF
A/C COMPRESSOR CLUTCH RELAY
AUDIO- HVAC DISPLAY UNIT (W/O USB ADAPTER)
AUTOMATIC DIMMING INSIDE MIRROR (IF EQUIPPED)
AUTOMATIC DIMMING INSIDE MIRROR CONNECTOR (OPTION CONNECTOR)
CLIMATE CONTROL UNIT (AUTOMATIC A/C)
FACTORY
FAN CONTROL RELAY
FROM FUSE 37 (DIAGRAM 8 OF 9)
FRONT BLOWER MOTOR RELAY
FUSE
HAC
HONDA ACCESSORY
HVAC CONTROL UNIT (MANUAL A/C)
LEFT SECOND ROW SEAT HEATER SWITCH
MANUAL AUTOMATIC A/C A/C
MICU
POWER MIRROR SWITCH
POWER WINDOW MASTER SWITCH
RADIATOR FAN RELAY
REAR BLOWER MOTOR RELAY
REAR FUSE/ RELAY BOX (LEFT SIDE OF CARGO AREA)
REAR MODE CONTROL MOTOR
REAR REAR HVAC CLIMATE CONTROL CONTROL PANEL PANEL
REAR WINDOW DEFOGGER RELAY RADIATOR FAN DIODE
REARVIEW MONITOR MIRROR (REARVIEW MONITOR, REARVIEW CAMERA)
RED WIRE
RELAY (W/ FACTORY INSTALLED TRAILER LIGHTING CONNECTOR)
RIGHT SECOND ROW SEAT HEATER SWITCH
SECOND ROW SEAT HEATERS
TO AC INVERTER UNIT (DIAGRAM 3 OF 9)
TRAILER LIGHTING CONTROL UNIT CONNECTOR (OPTION CONNECTOR)
TRAILER)
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT)
W/ CLIMATE CONTROL W/O CLIMATE CONTROL
W/O FACTORY-INSTALLED TRAILER LIGHTING CONNECTOR
YEL WIRE
Go to component -> Power distribution circuit (9 of 9) -> LEFT SECOND ROW SEAT HEATER SWITCH
