Honda Pilot II facelift (2011-2015) k-line scs Wiring diagram
This page shows the only wiring diagram for the component.k-line scs, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram k-line scs (1 of 1)
7 11 1 K-LINE F-CAN LO F-CAN HI
AUDIO UNIT (W/O NAVIGATION)
AUDIO-NAVIGATION UNIT (W/ NAVIGATION)
BLK WIRE
BRN WIRE
DATA LINK CONNECTOR (DLC) (UNDER LEFT SIDE OF DASH)
DIAG
ENGINE MOUNT CONTROL UNIT (BEHIND RIGHT KICK PANEL)
F-CAN HI
F-CAN LO
F-CAN LO F-CAN HI
GAUGE CONTROL MODULE
GRY WIRE
HOT AT ALL TIMES UNDER-HOOD FUSE/RELAY BOX (RIGHT SIDE OF ENGINE COMPT) FUSE 23
IMMOBILIZER KEYLESS CONTROL UNIT
K LINE
K-LINE F-CAN HI F-CAN LO
K-LINE SCS
LT BLU WIRE
MICU
NAVIGATION SERVICE CHECK CONNECTOR (UNDER DRIVER'S SEAT)
PCM (RIGHT SIDE OF ENGINE COMPT)
RED WIRE
REMOTE STARTING SYSTEM CONNECTOR (OPTION CONNECTOR) (UNDER LEFT SIDE OF DASH)
SCS
SCS F-CAN-HI F-CAN-LO
SRS UNIT (UNDER MIDDLE OF DASH)
TPMS CONTROL UNIT
UNDER-DASH FUSE/RELAY BOX (UNDER LEFT SIDE OF DASH)
VSA MODULATOR CONTROL UNIT (LEFT SIDE OF ENGINE COMPT)
VTM-4 CONTROL UNIT
WEN
WHT WIRE
YAW RATE-LATERAL/ LONGITUDINAL ACCELERATION SENSOR (UNDER MIDDLE OF DASH)
YEL WIRE
Go to component -> Data link connector circuit -> K-LINE SCS
