Honda Pilot II facelift (2011-2015) driver's seat position ods sensor unit Wiring diagram
This page shows the only wiring diagram for the component.driver's seat position ods sensor unit, which is found in the car Honda Pilot II facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver's seat position ods sensor unit (1 of 1)
A/T GEAR POSITION INDICATOR PANEL LIGHT/PARK PIN
ACTIVE NOISE CANCELLATION UNIT
AUTOMATIC LIGHTING CONTROL UNIT
BLK WIRE
DLC
DRIVER'S SEAT POSITION ODS SENSOR UNIT
FRONT ACCESSORY POWER SOCKET
FRONT ACCESSORY POWER SOCKET RELAY
FRONT PASSENGER'S POWER SEAT ADJUSTMENT SWITCH
FRONT PASSENGER'S POWER WINDOW MOTOR
FRONT PASSENGER'S POWER WINDOW SWITCH
FRONT PASSENGER'S SEAT BELT BUCKLE SWITCH
GLOVE BOX LIGHT
NAVIGATION INTERFACE DISPLAY DIAL UNIT
NCA WIRE
PARK-PIN SWITCH SWITCH
PNK WIRE
RIGHT REAR POWER WINDOW SWITCH
RIGHT REAR ROW SEAT DOOR LOCK HEATER ACTUATOR/ RELAY (HIGH) KNOB SWITCH
SRS UNIT
W/ CLIMATE CONTROL
W/ FRONT PASSENGER'S POWER SEAT W/ DRIVER'S POWER SEAT W/O MEMORY W/ MEMORY
W/ NAVIGATION
W/ PARKING, BACK- UP SENSOR SYSTEM
W/O CLIMATE CONTROL
W/O DRIVER'S POWER SEAT
W/O FRONT PASSENGER'S POWER SEAT
W/O MEMORY
YAW RATE, LATERAL, LONGITUDINAL ACCELERATION SENSOR
Go to component -> Ground distribution circuit (3 of 5) -> DRIVER'S SEAT POSITION ODS SENSOR UNIT
